• Screenless Operation – Eliminates screen clogging and downtime
• Whizzer Classifier System – Controls particle size by adjusting clearance between blade tips and cone wall
• Uniform Feeding – Rotary feeder ensures consistent material flow into the grinding chamber
• Heavy-Duty Construction – Main shaft supported by robust bearings for vibration-free performance
• Air-Tight Body Design – Prevents dust leakage and maintains a clean working environment
• High-Speed Grinding – Efficiently pulverizes a wide range of dry materials
• Low Maintenance – No screens to replace; easy access to internal components

Available Model OF Mutlipurpose Vegetable Cutter

Model No.	No. of Hammer	Required HP	Dimension of Machine (Feet)	Production Capacity
TW-TGM-12	8	7.5 HP	10′ x 10′ x 10′	200-25 kg/hr
TW-TGM-16	8	15 HP	10′ x 10′ x 10′	70-75 kg/hr
TW-TGM-20	8	20 HP	10′ x 10′ x 11′	125-130 kg/hr
TW-TGM-25	8	30 HP	10′ x 10′ x 11′	200-250 kg/hr
TW-TGM-32	8	40 HP	10′ x 10′ x 13′	400-425 kg/hr
TW-TGM-32B	16	60 HP	12′ x 10′ x 16′	500-550 kg/hr
TW-TGM-42	16	100 HP	20′ x 12′ x 20′	1000-1100 kg/hr
TW-TGM-42B	16	125 HP	20′ x 12′ x 20′	1200-1400 kg/hr
TW-TGM-52	20	175 HP	20′ x 12′ x 20′	1400-1700 kg/hr
TW-TGM-62	24	200 HP	20′ x 15′ x 20′	1700-2000 kg/hr

Applications of Impact Pulverizer(Screen Less pulverizer)

• Spice grinding (turmeric, chili, coriander, black pepper, etc.)
• Ayurvedic and herbal product manufacturing
• Chemical and mineral powder processing
• Food ingredients (sugar, salt, rice flour, etc.)
• Agricultural and feed materials

Working Principle of Impact Pulverizer(Screen Less pulverizer)

Feeding: Material is introduced through a rotary feeder into the grinding chamber.

Grinding: High-speed rotating hammers or beaters impact the material, reducing it to fine particles.

Classification: Instead of screens, a whizzer cone separates fine particles by adjusting the clearance between the blade tips and the cone wall.

Discharge: The desired fine powder is discharged through an outlet, while coarser particles are recirculated for further grinding.

Dust Control: The air-tight design minimizes dust emissions, and optional dust collectors can be integrated for enhanced hygiene.

Frequently Asked Questions Impact Pulverizer(Screen Less pulverizer)

Q1: What makes this a “screenless” pulverizer?

Unlike traditional models, this machine uses a whizzer classifier instead of screens, eliminating clogging and reducing maintenance.

Q2: What materials can it process?

It’s ideal for dry spices, herbs, grains, chemicals, minerals, and similar materials.

Q3: What is the output capacity?

Depending on the model and material, it can process 50 to 500 kg/hr.

Q4: Can I control the fineness of the powder?

Yes, the particle size is controlled by adjusting the clearance in the whizzer cone, allowing for consistent and customizable output.

Q5: Is it suitable for continuous operation?

Absolutely. The screenless design supports non-stop grinding with minimal downtime.
