Key Features of Continuous Conveyorised Dryers
- Continuous Operation – Designed for non-stop drying with minimal manual intervention
- Variable Conveyor Speed – Adjustable belt speed for precise control of drying time
- Multi-Zone Heating – Independent temperature zones for staged drying
- Hot Air Circulation – Uniform airflow ensures consistent moisture removal
- Modular Design – Available in 3 to 5 compartments for scalable capacity
- Energy-Efficient Heating – Options include steam, thermic fluid, hot air generators, or electric heaters
- Stainless Steel Contact Parts (SS304/SS316) – Hygienic and corrosion-resistant
- Moisture Exhaust System – Automatic exhaust valves for efficient vapor removal
Available models of continuous conveyorised dryers
| Specification | Unit | JAS-RCD-0250 | JAS-RCD-0500 | JAS-RCD-0750 | JAS-RCD-0900 |
|---|---|---|---|---|---|
| Power Supply | V/Ph/Frequency | 380 ± 10%/3 Ph/50 Hz ± 5%, AC | |||
| Rated Input Power | kW | 62 | 123 | 183 | 215 |
| Max. Power Input | kW | 90 | 180 | 250 | 290 |
| Dehydration Capacity | L/hr | 200 | 400 | 600 | 700 |
| Dehydration Capacity | L/day | 4800 | 9600 | 14400 | 16800 |
| Air Supply Method | Bottom Exhaust, Top Return Air | ||||
| Processing Capacity | Tons/24 Hour | 5–6 | 10–12 | 15–18 | 20–21 |
| Processing Capacity | Kg/hr | 208–250 | 415–500 | 625–750 | 833–875 |
| Refrigerant | Type | Eco-Friendly | |||
| Electric Shock Protection Grade | Class I | ||||
| Protection Grade | IPX4 | ||||
| Number of Heat Pump | Numbers | 2 | 4 | 6 | 7 |
| Number of Mesh Belt Layer | Layers | 3 | 3 | 3 | 3 |
| Maximum Outlet Air Temperature | °C | 75 | 75 | 75 | 75 |
| Noise Level | dB(A) | ≤75 | ≤75 | ≤75 | ≤75 |
| Heat Pump Dimensions | M | 2.2 × 2.2 × 1.8 | 2.2 × 2.2 × 1.8 | 2.2 × 2.2 × 1.8 | 2.2 × 2.2 × 1.8 |
| Mesh Belt System Dimension | M | 8 × 2.2 × 2.3 | 15 × 2.2 × 2.3 | 25 × 2.2 × 2.3 | 35 × 2.2 × 2.3 |
| Overall Dimension | M | 14 × 5 × 3.2 | 21 × 5 × 3.2 | 31 × 5 × 3.2 | 35 × 5 × 3.2 |
| Net Weight | Tons | 7 | 13 | 18 | 20 |
Applications of Continuous Conveyorised Dryers
- Food Industry: Fruits, vegetables, spices, herbs, seeds, noodles
- Pharmaceuticals: Herbal extracts, granules, powders
- Chemicals: Pigments, resins, fertilizers, polymers
- Agriculture: Animal feed, biomass, agro-waste
- Cosmetics: Clay, herbal powders, botanical ingredients
Working Principle of Continuous Conveyorised Dryer
Feeding: Wet material is loaded onto a perforated conveyor belt.
Drying Zones: As the belt moves, the material passes through heated compartments with controlled airflow.
Hot Air Circulation: Centrifugal blowers circulate hot air uniformly across the product surface.
Moisture Removal: Moist air is exhausted through vents or automatic valves.
Discharge: Dried product exits at the end of the conveyor, ready for packaging or further processing.
Frequently Asked Questions: Continuous Conveyorised Dryer
Q1: What materials can be dried in this machine? It’s suitable for food items, pharmaceuticals, chemicals, herbal products, and agricultural materials.
Q2: What heating options are available? Heating can be done via steam, thermic fluid, a hot air generator, or electric heaters.
Q3: Can the drying time be adjusted? Yes, the conveyor speed and temperature zones are fully adjustable for different products.
Q4: What is the typical drying temperature range? Up to 100°C, depending on the product and process requirements.
Q5: Is it suitable for continuous production lines? Absolutely. It’s designed for automated, high-volume drying with minimal downtime.
